Ø Two power panel slots support mutual hot spare between two power units. Each power unit can support the entire rack work full of
configuration. Two power units work together through shunt on the one hand to reduce each power unit load on the other hand by
mutual hot spare to ensure if one power unit having problem within the time rack inner function panel can work
Ø Support SNMP Network Managementu Power
Power supply:AC180V ~ 260V；DC–48V；DC +24V
Maximum number of power modules: 2 power modules
Maximum power parameters of the function card: DC5V/1.5A (7.5W)
Power consumption: 100W
u Dimension
Product size: 443X365X271mm(WXDXH)
Piece weight : 15KG
Working temperature: -10°C ~ 50°C
Working Humidity: 5%~95 % (no condensation)
Storage temperature: -40°C ~ 80°C
Storage Humidity: 5%~95 % (no condensation)
