? SD, HD, 3G automatically detects input, support 270Mbit / s - 1.48Gbit / s - 3Gbit / s rate; support new FULL HD Full HD 1080P / 60HZ
3Gbps HD-SDI format signal,Transmission distances of up to 80KM;
? support SMPTE 424M (2.97Gbps / s), SMPTE 292M (1.485Gbps / s), SMPTE 344M (540Mb / s), SMPTE 259M (360Mb / s)
and DVB-ASI (270Mb / s)
? band transmitter automatic cable equalization, 80M: 2.97Gb / s, 140M: 1.485Gb / s 250M: 270Mb / su 3Gbps HD-SDI Video
Video bandwidth：270Mb/s – 2.97Gb/s
TV signals：SMPTE 424M、SMPTE 292M、SMPTE 344M、SMPTE 259M和 DVB-ASI
Reflection loss：>15DB
Balanced： 250m @ 270Mbit/s,140m @ 1.485Gbit/s,80m @ 2.97Gbit/s
Interface: 75 BNC
u Audio
Audio input & output Level: 0.5-4Vp-pInterface Port: RJ45/RCA
u Date interface
Data Interface: RS-232、RS-422、RS-485、TTL
Data Mode: NRZ、Manchester、Bi-phase
Data Rate: 110bps-115.200Kbps
Interface Port: RJ45
u Switch
Respond Time: <0.5ms
Switch Signal: 30VDC/0.5A
u Optical
Respond Time: <0.5ms
Switch Signal: 30VDC/0.5
Ringing voltage：75V
Ringing frequency：25HZ
Wave Length：1470,1490,1510,1530,1550,1570,1590和1610nm
Fiber：Single-mode Fiber 9/125um
Optical interface：FC 、SC、ST
Fiber Transmission Distance is limited by optical circuit loss and additional loss as a result of connectors, fittings and patch panel.
Transmission distance may also be limited by fiber optic bandwidth.
u Power
Power supply: AC180V ~ 260V；DC –48V；DC +24V
Power consumption: ≤5W
u Dimension
Product Size: 186X138X31mm(WXDXH)
Piece Weight : 1.5KG
u Working environment
Working temperature: -10°C ~ 50°C
Working Humidity: 5%~95 % (no condensation)
Storage temperature: -40°C ~ 80°C
Storage Humidity: 5%~95 % (no condensation)
Applications
